BG-TLD Optical fiber laser detector
Fiber laser detector is a new generation of high-power laser detector developed by our factory. It is especially aimed at the harsh working sites of the metallurgical industry, and uses a high-power semiconductor infrared laser tube with a laser peak power of 60W as the emission source, so it has a strong penetrating ability and a long operating distance.
If you need this product, click to consult!
Product Details
Product Details
Technical parameters:
1. Detection area (distance between transmission and reception): ≤ 100m；
2. Emission light source: Infrared semiconductor laser with a wavelength of 905nm;
3. Peak power of transmission output: 60W;
4. Laser safety level: CLASS IIIb；
5. Output:
L transmitter: When the transmitter is working normally, the relay is disconnected; When the transmitter is working abnormally, the relay closes. Maximum load capacity DC30V/10A, 250VAC/10A
Receiver: A set of push-pull level outputs with a maximum load capacity of 100mA, equipped with overload protection and short circuit protection. The output polarity can be switched through an internal toggle switch with a response time of 10ms.
A set of relay outputs: response time of 20ms, maximum load capacity of DC30V/10A, 250VAC/10A
Optional energy receiving alarm output: MOS relay output, maximum load capacity DC60V/2.5A. When the received energy is ≤ 20, the MOS relay closes
6. Environmental temperature range:- 25℃~70℃
7. Optical unit:- 25℃~200℃
8. Power consumption: transmitter 5W; Receiver no-load power consumption 5W, full load power consumption 15W
9. Anti environmental light drying: 10000LUX, suitable for detecting objects below 1200 ℃.
